In GstarCAD 2022, the plot functionalities improved significantly, making plotting effects more precise and accurate.

In addition, an upgraded raster engine has been integrated and enables more image formats; even 1 billion pixels of images can be correctly attached, previewed, modified, and plotted.

Beyond, GstarCAD 2022 offers a plethora of other new and improved tools to help maximize your productivity.


PDF Plot Driver


When you plot with any options in GstarCAD 2022, the TTF (Truetype fonts) text is output as searchable and editable text with smooth border display, no matter how you set the value of text width factor and oblique angle.








GSTARCAD 2021
GSTARCAD 2022
Comparison PDF Plot result with TTF front


Hyperlinks are retained and remain clickable when plotted to PDF.


Third-party tools can easily read all information of the PDF plotted from GstarCAD 2022, and you are able to search, copy text and add electronic signatures, etc.



Plot with Transparency.


The display after plotting with transparency is much more precise and more accurate; the arcs, circles, ellipses, graphics, and text boundaries are smoother. And the drawing information after plotting will not be modified, all kinds of objects can be plotted correctly.





GSTARCAD 2021
GSTARCAD 2022
Comparison of two plots with transparency



GSTARCAD 2021
GSTARCAD 2022
Comparison of two plots with transparency

The raster images can be plotted with transparency perfectly in GstarCAD 2022.

GSTARCAD 2021
GSTARCAD 2022
The Line Weight and Line Type are displayed correctly after plotting with transparency.

The Line Weight and Line Type are displayed correctly after plotting with transparency.



GSTARCAD 2021
GSTARCAD 2022
The annotative objects are displayed accurately and in high quality after plotting with transparency in GstarCAD 2022.

The annotative objects are displayed accurately and in high quality after plotting with transparency in GstarCAD 2022.

Raster Images Plot



Large raster images in different sizes and formats can be previewed and plotted smoothly, in GstarCAD 2022, you are able to plot even 1 billion pixels images.

The plotting speed of 1-Bit and 32-Bit color raster images increases exponentially in GstarCAD 2022.

When you plot a raster image to PDF, the size of the plotted PDF file is greatly reduced, while its original details are fully retained, as well as keeping the high quality of plotting in GstarCAD 2022.





Raster Images Plot



The display after plotting rotated or cropped raster images is more accurate, and images after plotting will not have any offset.

GSTARCAD 2021
GSTARCAD 2022


Hidden Shade Plot



The display after hidden shade plotting is significantly improved, which is much more accurate and clearer than before. And the lines, polylines, arcs, circles, ellipses and other objects after hidden shade plotting now have smoother boundaries.

GSTARCAD 2021
GSTARCAD 2022








Raster Images



Formats



183 formats are available to be attached in GstarCAD 2022, greatly improving the compatibility of raster images.

You can attach, preview, modify and plot raster images in different formats and sizes, even 1 billion pixels raster image is supported.






Display



In GstarCAD 2022, the effects of brightness, contrast, fade, and highlight modification are more accurate, the display after modification is also becoming better.

And, the display of attached images with transparency is more accurate when the ‘Background transparency’ is set to Yes.

GSTARCAD 2021
GSTARCAD 2022


DIMENSION FEATURES


The DIMREASSOCIATE command allows associating or reassociating selected dimensions to objects or points on objects.







The DIMREGEN command allows updating the positions of all associative dimensions in Model space or Layouts.







A new option Polygon(P) has been added to DIMCENTER command, which allows you to mark center of polygons easily.






The “Stretch dimension group” option in the dynamic grip menu allows adjusting all dimensions which share grips with each other at once.








The system variable DIMLAYER specifies a default layer for dimensions, and basic dimensions will be created on that layer automatically instead of creating dimensions on current layer.






 NEW

ACET Interfaces


There are 351 ACET (AutoCAD Express Tools) interfaces supported in GstarCAD 2022. Now, more AutoCAD Express Tools and ‘Plug-in’ functionalities developed with these interfaces can be operated properly.






 NEW

FASTSEL


In GstarCAD 2022, the fast select command FASTSEL allows selecting all the objects that touch the selected object, including lines, polylines, circles, arcs, attribute definitions, text, Mtext, ellipses, and images. The system variable FSMODE controls two different behaviors of the FASTSEL command.






UNIQUE

LAYULKALL


In GstarCAD 2022, you can select LAYULKALL command to unlock all the locked layers immediately, instead of unlocking them one by one.






UNIQUE

CHANGEBASE


In GstarCAD 2022, the CHANGEBASE command allows changing the base point position of a block. You can move the base point and keep objects staying in same position, or move objects and keep base point staying in same position.






UNIQUE

LAYDRAWORDER


The LAYDRAWORDER feature allows rearranging the layers in GstarCAD 2022. You are able to select one or more layers, and bring them to front or send them to back with buttons in ‘Layer Draw Order’ window. You can also change the order of the layers in ‘Layers to Adjust Draw Order’ list conveniently.






UNIQUE

DIMTOFFSET


In GstarCAD 2022, if the space above the arrows is not enough for dimension text when you place the dimension below or right the objects, the text will be placed downward. In this case, you can use two values of the system variable DIMTOFFSET to set two kinds of gap styles between the arrows and text, one is the same as AutoCAD, the other reduces the gap.
