LEARNING GSTARCAD 1 – BASIC

LEARNING GSTARCAD 1 – BASIC

The course offers foundational knowledge needed to create simple, annotated drawings and further prepares the learner to develop GstarCAD skills.

RM 30.00
30.0 MYR RM 30.00
RM 30.00
Add to Cart
Last Update 03/Jun/2023
Completion Time 1 hour 41 minutes
Members 1125
    • Introduction
    • Training exercise files
  • 1. The GstarCAD Interface
    4Lessons ·
    • 1. The application menu
    • 2. The ribbon and panels
    • 3. Dialog boxes and palettes
    • 4. The status bar
  • 2. Drawing Simple Geometry
    5Lessons ·
    • 1. OSNAP (object snap) and OTRACK (object snap tracking)
    • 2. POLAR (polar tracking) and ORTHO (orthogonal mode)
    • 3. Lines, arcs, and circles
    • 4. Polylines, polygons, and splines
    • 5. Using ZOOM and PAN
  • 3. Annotating Simple Designs
    5Lessons ·
    • 1. Text styles
    • 2_Single line text (TEXT) and multiline text (MTEXT)
    • 3. Dimension styles
    • 4. Placing dimensions
    • 5. Adding a simple table
  • 4. Communication Your Design Intent
    6Lessons ·
    • 1. Creating a simple title block
    • 2. Defining your page setup
    • 3. Adding new layouts and scaled viewports
    • 4. Using annotative scaling
    • 5. Printing and plotting
    • 5-1 Configuring GstarCAD plot drivers
  • Quiz / Certification
    1Lessons ·
    • Certification - GstarCAD Basic
