GSTARCAD 2020

THE MOST DESIRABLE ALTERNATIVE CAD





New Interface

GstarCAD 2020 offers you a concise and familiar interface that you can easily customize with the new attractive color theme and icon designs.


GSTARCAD 2019
GSTARCAD 2020 (NEW)


  Quick properties are a set of objects properties displayed through the properties palette. In addition, GstarCAD 2020 can customize your own quick properties to meet your needs.



3D EDITING


GstarCAD 2020 brings you an amazing 3D with the comprehensive reconstitution for the 3D system, improved 3D performance, 3D functionalities, display effect, and accuracy.



3D EDITING







3D VISUAL






PDF IMPORT


Import TrueType text, the geometry, and raster images from a PDF file or underlay into a current drawing as GstarCAD objects.

GRX interface


GstarCAD offers a friendly secondary development interface; until now, GstarCAD has been cooperating with hundreds of developers worldwide to provide industrial solutions for customers.

.IFC BIM File format


Since IFC format supports the latest GstarCAD, you can import and export standard IFC file format and view 3D models by category and operate in GstarCAD conveniently.





JOIN


The JOIN command in GstarCAD 2020 supports more objects, and Now the JOIN command is supporting line and polyline and support arc and spline.






ULTRA HD 4k DISPLAY


GstarCAD 2020 adapts the ultra HD 4K screen resolution from interface to dialog boxes.



Online Collaboration

COLLABORATE ON DWG-BASED DRAWING WITH REAL-TIME CO-DESIGNING
